General Data

125kW/260kWh

Dimension (W*D*H mm,w/o inverter)

1120*2387*1400

Weight (tons)

2.6

Working Temperature Range(℃)

-25-50*

Protection Class

IP55

Altitude(m)

≤3000

Humidity

5%-95%

Fire extinguishing

Aerosol

Cooling System

Liquid Cooling

Max.parallel No.

10

Anti-corrosion

C3(C5 Optional)

Certification*

IEC62619/CE/RoHS/UN38.3

Battery Data

Battery Type

Li-ion (LFP)

Nominal Capacity (kWh)

261

Depth of Discharge

98%(single string)

Cycle Life

>8000

DC Voltage Range(Vdc)

702-936(single string)

Max./Continuous Operation Current (A)

200/157

Round-trip Effciency@0.5C-rate

>95%

PCS DC/AC Data On-grid Mode

Rated AC Power(kW)

125

Rated AC Output Voltage(Vac)

400

Rated AC Output Frequency(Hz)

50

Max AC Current(A)

181

Overload Capacity

110%

AC PF

1.0 (Lagging)~1.0 (Leading)

CEC Efficiency

98%

Isolation Type

Non-isolation

Operation Mode

Communication Type

Ethernet(Modbus TCP)

Operation Logic

Wide Temp Range/Ancillary Service/Electricity Arbitrage/Demand Response/Backup
